机床特点

1、数控立式车床是一种性能良好，工艺范围广泛，生产效率高的先进设备。适用于各行业机械加工，可用于内外圆柱面、内外圆锥面、端面、切槽、圆弧面及各种曲线面、螺纹的粗、精加工。

2、机床主传动为交流电机驱动。交流经 16 级或 4 级主轴变速机构：实现工作台的转速范围。

3、工作台主轴采用了高精度可调径向间隙双列短圆柱滚子轴承定心。工作台采用恒流静压导轨，使工作台具有旋转精度高，承载能力大。热变形小的特点。4、根据用户需要机床可采用恒温冷却装置，可设有独立液压站系统，能保证机床加工精度和各项技术指标稳定性。

5、立柱、横梁、滑枕等导轨面采用了精磨。精度高、质量好。

6、机床进给采用伺服电机，滚珠丝杠传动。横梁、垂直刀架配有封闭护罩。增加了机床安全性。

7、滑枕改为方滑枕，滑枕截面尺寸大，钢性好，横梁上面与滚轮接触面采用镶钢结构。

The lathe features

1、The CK52 series single-column CNC vertical lathe is an advanced machine tool with excellent performance, wide processing range and high production efficiency. It is suitable for mechanical processing in various industries, and can perform rough and finish machining of internal and external cylindrical surfaces, internal and external conical surfaces, end faces, grooving, circular arc surfaces, various curved surfaces and threads.

2、The main drive of the machine tool is driven by an AC motor. Equipped with a 16-speed or 4-speed spindle gear mechanism, it realizes a wide rotating speed range of the worktable.

3、The worktable spindle is positioned by high-precision double-row short cylindrical roller bearings with adjustable radial clearance. The worktable adopts a constant-current hydrostatic guideway, which delivers high rotational accuracy, large load capacity and low thermal deformation.

4、According to customer requirements, the machine tool can be equipped with a constant temperature cooling device and an independent hydraulic station system, ensuring stable machining accuracy and reliable technical performance.

5、The guideway surfaces of the column, crossrail and ram are precision ground, featuring high accuracy and superior quality.

6、The feed system adopts servo motor and ball screw transmission. The crossrail and vertical tool post are fitted with fully enclosed protective covers to enhance operational safety.

7、The ram is designed as a square type with a large cross-section size and high rigidity. The contact surface between the crossrail and the roller adopts an inserted steel structure.
